750 mm (2′ 4½″) diam., 9 oval spokes, vee inner rim, 75 mm apparent tread.
Hub 9″ face dia., 15 mm out from the tyre.

Casting: 23.4 mm tread dia., 18.8 i/d, hub 0.5 mm out from the tyre.

Scans of a casting in a set for a Swedish Sexan
